VLA calibrator information for 1400+6210

This page summarizes the information for 1400+6210 as found in the original VLA calibrator list and, if found there, a link to search the NRAO VLA Archive Survey (NVAS) for calibrator data before 2010. Furthermore, a table with the most recent approximate flux densities, starting from 2017 as mined from the VLA CASA pipeline is presented.

If shown at the top, we have recovered the original, pre-WIDAR ANTSOL flux density solutions from the period roughly 2000-2007; symbols as explained next.
The mined data are plotted (gray, on the left hand side) as function of (log) frequency on the top and as function of time on the bottom. The frequency band symbols in the bottom panel follow the symbols as outlined in the top panel:

4-band  (~75 MHz) horizontal stripe       X-band (~10.0 GHz) cross
P-band (~350 MHz) open triangle        U/Ku-band (~15.0 GHz) filled square
L-band (~1.5 GHz) VLA-Y shape             K-band (~22.2 GHz) open circle
S-band (~3.0 GHz) filled triangle      A/Ka-band (~33.2 GHz) 6-pointed star
C-band (~6.0 GHz) open square             Q-band (~45.0 GHz) filled circle
Assume a 10% flux density error on each point, up to 30% for the higher frequency data points. The dashed lines in the frequency plot indicate the approximate spectral index in the frequency band (tied to the measured flux density).
Depending on the spectral behavior, different receiver observing bands (as indicated with the log-frequency axis) may have very different typical flux densities. Note that there can be significant flux density changes for different array configurations, which start date is indicated at the top of the time-line figure. Calendar years are separated by vertical dotted lines.
If shown, a curve depicts a fit to the (unweighted) average data for each band (if there are more than two bands with measured flux densities). The fit equation is listed at the top where the x-coordinate represents the base-10 log of the frequency (GHz) and the y-coordinate represents the base-10 log of the flux density (mJy/bm). The fit may use more data than shown and is using data with different time stamps, which means typically different flux densitities in a single band for genuine variable sources (and/or observed in different array configurations).
Depending on the variability of the source, array configuration and the quality of the data, this fit may, or may not, be representative for the data!

(Click on the figure for a larger view in a new tab/window)

Original (outdated) VLA calibrator list information:
 IAU NAME EQUINOX  PC RA(hh,mm,ss)    DEC(ddd,mm,ss)   POS.REF ALT.NAME
 ===================================================================
 1400+621   J2000  C 14h00m28.6526s    62d10'38.526"
 1358+624   B1950  C 13h58m58.3600s    62d25'06.700"
 -----------------------------------------------------
 BAND        A B C D    FLUX(Jy)    UVMIN(kL)  UVMAX(kL)
 =====================================================
  20cm    L  P P P P       4.40
   6cm    C  P P P P       1.72
 3.7cm    X  S P P P       1.08                      400
   2cm    U  X S S S       0.67                      400
 1.3cm    K  X X S S       0.48                      400
 0.7cm    Q  X X W W       0.28                      400

Default NVAS search around this position (in new tab/window)

WARNING: multiple positions found, using first one 210.1193750 +62.1773667 210.1193858 +62.1773683 Results from CASA pipeline flux density mining:
Observing date (UT)Flux density (Jy/bm)Source name used
C-band data (open squares)
201708281.417J1400+6210
X-band data (X-crosses)
201708280.940J1400+6210
201705294.156J1400+6210
201706064.196J1400+6210
201706074.186J1400+6210
201706224.189J1400+6210
201706234.187J1400+6210
201707094.156J1400+6210
201707124.180J1400+6210
201707134.179J1400+6210
201707144.222J1400+6210
201707154.197J1400+6210
201707154.174J1400+6210
201707164.195J1400+6210
201707164.194J1400+6210
201707174.169J1400+6210
201707214.159J1400+6210
201707234.152J1400+6210
201707244.186J1400+6210
201707254.178J1400+6210
201707254.204J1400+6210
201707254.193J1400+6210
201707274.184J1400+6210
201708044.151J1400+6210
201708044.169J1400+6210
201708054.233J1400+6210
201708054.178J1400+6210
201708064.165J1400+6210
201708064.204J1400+6210
201708074.179J1400+6210
201708084.168J1400+6210
201708094.202J1400+6210
201708124.185J1400+6210
201708134.185J1400+6210
201708134.188J1400+6210
201708134.173J1400+6210
201708134.175J1400+6210
201708134.170J1400+6210
201708154.196J1400+6210
201712284.179J1400+6210
201801124.205J1400+6210
201801214.162J1400+6210
201812024.193J1400+6210
201904284.153J1400+6210
201905024.129J1400+6210
201906234.146J1400+6210
201909033.973J1400+6210
201909304.090J1400+6210
202112064.186J1400+6210
202207294.172J1400+6210
202303084.143J1400+6210
202305274.158J1400+6210
201812022.459J1400+6210
201904282.488J1400+6210
201905022.507J1400+6210
201906232.509J1400+6210
201710021.385J1400+6210
201804131.406J1400+6210
201811301.363J1400+6210
201903031.411J1400+6210
201903041.413J1400+6210
201903091.406J1400+6210
201908031.359J1400+6210
201908151.409J1400+6210
202106191.393J1400+6210
202207031.414J1400+6210
202208051.421J1400+6210
202005280.865J1400+6210
202005290.913J1400+6210
202006010.924J1400+6210
K-band data (open circles)
202103280.468J1400+6210
202109140.482J1400+6210
A-band data (6-pointed stars)
202103290.330J1400+6210
