VLA calibrator information for 1125+2610

This page summarizes the information for 1125+2610 as found in the original VLA calibrator list and, if found there, a link to search the NRAO VLA Archive Survey (NVAS) for calibrator data before 2010. Furthermore, a table with the most recent approximate flux densities, starting from 2017 as mined from the VLA CASA pipeline is presented.

If shown at the top, we have recovered the original, pre-WIDAR ANTSOL flux density solutions from the period roughly 2000-2007; symbols as explained next.
The mined data are plotted (gray, on the left hand side) as function of (log) frequency on the top and as function of time on the bottom. The frequency band symbols in the bottom panel follow the symbols as outlined in the top panel:

4-band  (~75 MHz) horizontal stripe       X-band (~10.0 GHz) cross
P-band (~350 MHz) open triangle        U/Ku-band (~15.0 GHz) filled square
L-band (~1.5 GHz) VLA-Y shape             K-band (~22.2 GHz) open circle
S-band (~3.0 GHz) filled triangle      A/Ka-band (~33.2 GHz) 6-pointed star
C-band (~6.0 GHz) open square             Q-band (~45.0 GHz) filled circle
Assume a 10% flux density error on each point, up to 30% for the higher frequency data points. The dashed lines in the frequency plot indicate the approximate spectral index in the frequency band (tied to the measured flux density).
Depending on the spectral behavior, different receiver observing bands (as indicated with the log-frequency axis) may have very different typical flux densities. Note that there can be significant flux density changes for different array configurations, which start date is indicated at the top of the time-line figure. Calendar years are separated by vertical dotted lines.
If shown, a curve depicts a fit to the (unweighted) average data for each band (if there are more than two bands with measured flux densities). The fit equation is listed at the top where the x-coordinate represents the base-10 log of the frequency (GHz) and the y-coordinate represents the base-10 log of the flux density (mJy/bm). The fit may use more data than shown and is using data with different time stamps, which means typically different flux densitities in a single band for genuine variable sources (and/or observed in different array configurations).
Depending on the variability of the source, array configuration and the quality of the data, this fit may, or may not, be representative for the data!

(Click on the figure for a larger view in a new tab/window)

 Original (outdated) VLA calibrator list information:
 IAU NAME EQUINOX  PC RA(hh,mm,ss)    DEC(ddd,mm,ss)   POS.REF ALT.NAME
 ===================================================================
 1125+261   J2000  A 11h25m53.711925s  26d10'19.978680"  Aug01
 1123+264   B1950  A 11h23m14.869300s  26d26'49.991000"
 -----------------------------------------------------
 BAND        A B C D    FLUX(Jy)    UVMIN(kL)  UVMAX(kL)
 =====================================================
  20cm    L  P P P S       1.00
   6cm    C  P P P P       1.00
 3.7cm    X  P P P P       1.42
   2cm    U  S S S S       0.7
 0.7cm    Q  W W W W       0.4

Default NVAS search around this position (in new tab/window)

Results from CASA pipeline flux density mining:
Observing date (UT)Flux density (Jy/bm)Source name used
L-band data ("VLA Y-arm" symbols)
201809290.987J1125+2610
201809290.986J1125+2610
201905220.978J1125+2610
201909100.035J1125+2610
201909150.900J1125+2610
201910110.907J1125+2610
202301120.774J1125+2610
S-band data (filled triangles)
201706301.143J1125+2610
201801171.101J1125+2610
201902080.960J1125+2610
201902090.958J1125+2610
201904120.931J1125+2610
201904140.927J1125+2610
201907090.901J1125+2610
201907100.894J1125+2610
201907130.890J1125+2610
201907220.907J1125+2610
201907260.871J1125+2610
201907290.880J1125+2610
201908030.871J1125+2610
201908060.875J1125+2610
201908130.887J1125+2610
201908210.887J1125+2610
201908300.870J1125+2610
201909090.864J1125+2610
201909150.882J1125+2610
201909170.865J1125+2610
201909210.873J1125+2610
201910110.867J1125+2610
201910130.863J1125+2610
201910130.854J1125+2610
201910200.846J1125+2610
202111090.700J1125+2610
202112030.692J1125+2610
C-band data (open squares)
201706301.107J1125+2610
201801171.003J1125+2610
201803210.962J1125+2610
201804300.940J1125+2610
201902160.780J1125+2610
201907090.715J1125+2610
201907100.709J1125+2610
201907130.717J1125+2610
201907220.704J1125+2610
201907260.694J1125+2610
201907290.693J1125+2610
201908030.686J1125+2610
201908060.697J1125+2610
201908130.697J1125+2610
201908210.695J1125+2610
201908300.691J1125+2610
201909090.680J1125+2610
201909170.684J1125+2610
201909210.686J1125+2610
201910130.681J1125+2610
201910130.671J1125+2610
201910200.678J1125+2610
202107090.581J1125+2610
202107270.590J1125+2610
202112170.572J1125+2610
202206260.602J1125+2610
X-band data (X-crosses)
201706300.935J1125+2610
201711010.877J1125+2610
201711050.890J1125+2610
201801170.850J1125+2610
201802100.821J1125+2610
201903120.635J1125+2610
201903220.627J1125+2610
201907090.569J1125+2610
201907100.565J1125+2610
201907130.569J1125+2610
201907220.550J1125+2610
201907260.548J1125+2610
201907290.550J1125+2610
201908010.558J1125+2610
201908030.543J1125+2610
201908060.543J1125+2610
201908130.550J1125+2610
201908210.554J1125+2610
201908300.550J1125+2610
201909090.543J1125+2610
201909170.541J1125+2610
201909210.548J1125+2610
201910130.540J1125+2610
201910130.533J1125+2610
201910200.548J1125+2610
202103210.499J1125+2610
202107170.503J1125+2610
U-band data (filled squares)
201706300.791J1125+2610
201801170.718J1125+2610
201907090.480J1125+2610
201907100.478J1125+2610
201907130.488J1125+2610
201907220.472J1125+2610
201907260.463J1125+2610
201907290.466J1125+2610
201908030.459J1125+2610
201908060.469J1125+2610
201908130.473J1125+2610
201908210.473J1125+2610
201908300.458J1125+2610
201909090.460J1125+2610
201909170.454J1125+2610
201909210.466J1125+2610
201910130.460J1125+2610
201910130.459J1125+2610
201910200.465J1125+2610
