VLA calibrator information for 0319+4130

This page summarizes the information for 0319+4130 as found in the original VLA calibrator list and, if found there, a link to search the NRAO VLA Archive Survey (NVAS) for calibrator data before 2010. Furthermore, a table with the most recent approximate flux densities, starting from 2017 as mined from the VLA CASA pipeline is presented.

If shown at the top, we have recovered the original, pre-WIDAR ANTSOL flux density solutions from the period roughly 2000-2007; symbols as explained next.
The mined data are plotted (gray, on the left hand side) as function of (log) frequency on the top and as function of time on the bottom. The frequency band symbols in the bottom panel follow the symbols as outlined in the top panel:

4-band  (~75 MHz) horizontal stripe       X-band (~10.0 GHz) cross
P-band (~350 MHz) open triangle        U/Ku-band (~15.0 GHz) filled square
L-band (~1.5 GHz) VLA-Y shape             K-band (~22.2 GHz) open circle
S-band (~3.0 GHz) filled triangle      A/Ka-band (~33.2 GHz) 6-pointed star
C-band (~6.0 GHz) open square             Q-band (~45.0 GHz) filled circle

(Click on the figure for a larger view in a new tab/window)

Original (outdated) VLA calibrator list information: IAU NAME EQUINOX PC RA(hh,mm,ss) DEC(ddd,mm,ss) POS.REF ALT.NAME =================================================================== 0319+415 J2000 B 03h19m48.160102s 41d30'42.103050" Aug01 3C84 0316+413 B1950 B 03h16m29.567300s 41d19'51.916000" ----------------------------------------------------- BAND A B C D FLUX(Jy) UVMIN(kL) UVMAX(kL) ===================================================== 90cm P S X X X 8 13 20cm L P P X X 23.9 12 6cm C P P P P 23.3 3.7cm X P P P P 21.7 2cm U P P P P 20.7 1.3cm K X S S S 16.4 0.7cm Q X S S S 9.0 1800 Default NVAS search around this position (in new tab/window) Results from CASA pipeline flux density mining: Observing date (UT) Flux density (Jy/bm) Source name used K-band data (open circles) 20220617 27.276 3C84 20170925 13.709 3C84 20171031 13.631 3C84 20171103 13.490 3C84 20171104 13.687 3C84 20181229 14.638 3C 20181224 18.972 3C 20201221 30.954 NGC1275 20181202 22.702 NGC1275 Q-band data (filled circles) 20181202 18.239 NGC1275 20170617 14.761 J0319+4130 20170624 14.676 J0319+4130 20170624 14.933 J0319+4130 20170625 14.621 J0319+4130 20170625 14.735 J0319+4130 20170625 14.830 J0319+4130 20170626 14.767 J0319+4130 20170626 14.698 J0319+4130 20170626 14.859 J0319+4130 20170629 14.829 J0319+4130 20170709 14.601 J0319+4130 20170820 14.788 J0319+4130 20170822 14.849 J0319+4130 20170923 13.608 J0319+4130 20171005 1.145 J0319+4130 20171006 13.545 J0319+4130 20171013 13.623 J0319+4130 20171016 13.835 J0319+4130 20171017 13.753 J0319+4130 20171017 13.684 J0319+4130 20171019 13.588 J0319+4130 20171021 13.665 J0319+4130 20171022 13.630 J0319+4130 20171022 13.769 J0319+4130 20171026 13.736 J0319+4130 20171028 13.749 J0319+4130 20171029 1.132 J0319+4130 20171029 13.666 J0319+4130 20171030 13.625 J0319+4130 20171031 13.593 J0319+4130 20171103 13.760 J0319+4130 20171115 13.750 J0319+4130 20171119 13.756 J0319+4130 20171125 13.817 J0319+4130 20171201 13.843 J0319+4130 20171201 13.722 J0319+4130 20171205 13.570 J0319+4130 20171205 13.810 J0319+4130 20171208 13.694 J0319+4130 20171209 13.798 J0319+4130 20171214 13.585 J0319+4130 20171214 13.748 J0319+4130 20171215 13.582 J0319+4130 20171218 13.524 J0319+4130 20171218 13.566 J0319+4130 20171219 13.460 J0319+4130 20171219 13.598 J0319+4130 20180108 13.540 J0319+4130 20180110 13.574 J0319+4130 20180112 13.579 J0319+4130 20180112 13.499 J0319+4130 20180112 13.591 J0319+4130 20180113 13.437 J0319+4130 20180114 13.640 J0319+4130 20180116 13.611 J0319+4130 20180422 13.371 J0319+4130 20180422 13.735 J0319+4130 20180422 13.820 J0319+4130 20180426 13.397 J0319+4130 20190504 13.663 3C84 20190510 14.654 3C84 20190511 13.863 3C84 20190517 13.853 3C84 20190702 13.932 J0319+4130 20190723 14.197 J0319+4130 20190726 13.595 J0319+4130 20190810 14.044 J0319+4130 20190829 13.457 J0319+4130 20190906 13.838 J0319+4130 20190908 13.628 J0319+4130 20190908 13.680 J0319+4130 20210625 15.523 J0319+4130 20211207 14.588 J0319+4130 20211212 15.012 J0319+4130 20220618 14.706 J0319+4130 20220618 14.508 J0319+4130 20220619 14.696 J0319+4130 20220620 14.714 J0319+4130 20220817 16.775 J0319+4130 20221014 15.716 J0319+4130 20221015 15.787 J0319+4130 20221018 15.718 J0319+4130 20221018 15.785 J0319+4130 20221019 16.146 J0319+4130 20221019 15.936 J0319+4130 20230124 15.993 J0319+4130 20230304 15.019 J0319+4130 20230328 15.011 J0319+4130 20230409 14.970 J0319+4130 20230411 14.879 J0319+4130 20230416 14.900 J0319+4130 20230418 15.097 J0319+4130 20230421 15.056 J0319+4130 20230428 15.305 J0319+4130 20230505 15.188 J0319+4130 20230506 15.109 J0319+4130 20230507 15.159 J0319+4130 20230516 14.987 J0319+4130 20170617 16.729 J0319+4130 20170624 16.708 J0319+4130 20170624 16.712 J0319+4130 20170625 16.677 J0319+4130 20170625 16.653 J0319+4130 20170625 17.093 J0319+4130 20170626 16.741 J0319+4130 20170626 16.689 J0319+4130 20170626 16.832 J0319+4130 20170629 16.830 J0319+4130 20170820 17.476 J0319+4130 20170822 17.343 J0319+4130 20171215 17.628 J0319+4130 20180329 18.005 J0319+4130 20181214 19.053 J0319+4130 20190112 19.111 J0319+4130 20190119 18.851 J0319+4130 20190203 18.874 J0319+4130 20190223 18.543 J0319+4130 20190223 18.603 J0319+4130 20190225 18.706 J0319+4130 20190227 18.589 J0319+4130 20190314 19.057 J0319+4130 20190430 19.370 J0319+4130 20190430 19.479 J0319+4130 20190518 19.436 J0319+4130 20190702 19.647 J0319+4130 20190723 19.756 J0319+4130 20190827 19.239 J0319+4130 20190908 19.153 J0319+4130 20190908 19.545 J0319+4130 20190911 19.310 J0319+4130 20190916 19.575 J0319+4130 20190917 19.572 J0319+4130 20190921 19.548 J0319+4130 20190921 19.524 J0319+4130 20190922 19.528 J0319+4130 20190923 19.600 J0319+4130 20190926 19.660 J0319+4130 20190930 19.349 J0319+4130 20191004 20.047 J0319+4130 20191005 19.955 J0319+4130 20191005 19.855 J0319+4130 20210903 22.339 J0319+4130 20210907 22.461 J0319+4130 20220624 24.083 J0319+4130 20170526 31.526 J0319+4130 20170527 31.776 J0319+4130 20170530 32.053 J0319+4130 20170602 31.631 J0319+4130 20170811 31.269 J0319+4130 20170812 30.998 J0319+4130 20170813 28.499 J0319+4130 20170820 31.756 J0319+4130 20170822 32.265 J0319+4130 20170923 30.154 J0319+4130 20170923 29.778 J0319+4130 20170925 30.100 J0319+4130 20170926 29.905 J0319+4130 20170928 29.948 J0319+4130 20171002 29.917 J0319+4130 20171006 29.591 J0319+4130 20171027 29.067 J0319+4130 20171031 29.473 J0319+4130 20171031 29.739 J0319+4130 20171031 31.835 J0319+4130 20171101 29.327 J0319+4130 20171102 29.265 J0319+4130 20171102 29.325 J0319+4130 20171104 29.722 J0319+4130 20171105 29.449 J0319+4130 20171105 29.694 J0319+4130 20171106 29.079 J0319+4130 20171106 28.851 J0319+4130 20171108 29.330 J0319+4130 20171109 29.249 J0319+4130 20171111 29.968 J0319+4130 20171113 28.979 J0319+4130 20171114 29.048 J0319+4130 20171115 28.912 J0319+4130 20171116 29.125 J0319+4130 20171121 26.593 J0319+4130 20171127 28.500 J0319+4130 20171204 28.743 J0319+4130 20171206 28.977 J0319+4130 20171206 29.212 J0319+4130 20171207 28.700 J0319+4130 20171207 29.010 J0319+4130 20180303 28.211 J0319+4130 20180306 26.640 J0319+4130 20180402 27.095 J0319+4130 20180504 27.355 J0319+4130 20181208 28.985 J0319+4130 20181214 29.964 J0319+4130 20181215 29.727 J0319+4130 20190112 29.877 J0319+4130 20190112 29.286 J0319+4130 20190113 30.714 J0319+4130 20190115 29.523 J0319+4130 20190119 29.731 J0319+4130 20190123 29.117 J0319+4130 20190131 29.267 J0319+4130 20190203 29.743 J0319+4130 20190222 29.601 J0319+4130 20190227 29.475 J0319+4130 20190723 31.843 J0319+4130 20190805 30.515 J0319+4130 20190807 30.455 J0319+4130 20190808 30.234 J0319+4130 20190809 29.461 J0319+4130 20190810 30.639 J0319+4130 20190814 30.196 J0319+4130 20190819 30.433 J0319+4130 20190821 30.478 J0319+4130 20190822 30.487 J0319+4130 20190823 30.254 J0319+4130 20190825 30.363 J0319+4130 20190826 30.573 J0319+4130 20190827 26.068 J0319+4130 20190827 30.311 J0319+4130 20190828 30.337 J0319+4130 20190906 29.747 J0319+4130 20190908 30.861 J0319+4130 20190911 28.251 J0319+4130 20190911 30.641 J0319+4130 20190916 28.803 J0319+4130 20190917 30.872 J0319+4130 20190921 28.278 J0319+4130 20190921 30.318 J0319+4130 20190922 28.378 J0319+4130 20190923 30.742 J0319+4130 20190926 30.547 J0319+4130 20191007 31.405 J0319+4130 20191009 30.755 J0319+4130 20210119 32.242 J0319+4130 20210124 33.988 J0319+4130 20210124 32.135 J0319+4130 20210126 31.500 J0319+4130 20210208 31.955 J0319+4130 20210211 30.372 J0319+4130 20210211 31.424 J0319+4130 20210324 32.551 J0319+4130 20210611 32.521 J0319+4130 20210611 32.599 J0319+4130 20210626 32.146 J0319+4130 20210815 33.139 J0319+4130 20210815 33.213 J0319+4130 20210929 33.402 J0319+4130 20220319 33.634 J0319+4130 20220415 32.157 J0319+4130 20220527 36.964 J0319+4130 20220626 33.014 J0319+4130 20220701 34.009 J0319+4130 20220808 35.563 J0319+4130 20171005 1.390 J0319+4130 20171029 1.554 J0319+4130 20180213 31.970 J0319+4130 20180222 30.670 J0319+4130 20180222 30.736 J0319+4130 20180225 29.895 J0319+4130 20180225 29.959 J0319+4130 20180303 30.896 J0319+4130 20180321 1.749 J0319+4130 20180325 1.617 J0319+4130 20180329 33.739 J0319+4130 20180403 26.923 J0319+4130 20181110 31.928 3C84 20181114 32.367 3C84 20181214 31.034 J0319+4130 20181215 30.383 J0319+4130 20190115 30.128 J0319+4130 20190119 30.904 J0319+4130 20190203 30.685 J0319+4130 20190227 31.165 J0319+4130 20190301 31.215 J0319+4130 20190301 29.852 J0319+4130 20190306 31.396 J0319+4130 20190314 31.373 J0319+4130 20190314 31.861 J0319+4130 20190315 30.533 J0319+4130 20190320 31.061 J0319+4130 20190321 31.312 J0319+4130 20190325 32.188 J0319+4130 20190326 31.422 J0319+4130 20190327 31.218 J0319+4130 20190329 31.477 J0319+4130 20190402 31.958 J0319+4130 20190407 31.345 J0319+4130 20190413 30.886 J0319+4130 20190420 30.301 J0319+4130 20190425 32.089 J0319+4130 20190425 33.065 J0319+4130 20190426 33.533 J0319+4130 20190426 36.091 J0319+4130 20190427 32.121 J0319+4130 20190503 32.258 J0319+4130 20190508 33.016 J0319+4130 20190517 32.051 J0319+4130 20190517 31.864 J0319+4130 20190524 31.527 J0319+4130 20190531 32.025 J0319+4130 20190604 31.799 J0319+4130 20190611 32.098 J0319+4130 20190620 31.950 J0319+4130 20190723 33.636 J0319+4130 20190806 32.089 J0319+4130 20190809 29.375 J0319+4130 20190817 32.982 J0319+4130 20190819 33.073 J0319+4130 20190825 32.876 J0319+4130 20190906 31.177 J0319+4130 20190908 31.889 J0319+4130 20190912 31.712 J0319+4130 20190923 31.427 J0319+4130 20200609 32.741 J0319+4130 20201211 30.435 J0319+4130 20210120 30.972 J0319+4130 20210121 31.122 J0319+4130 20210123 31.234 J0319+4130 20210125 31.084 J0319+4130 20210321 31.337 J0319+4130 20210710 33.459 J0319+4130 20211205 34.793 J0319+4130 20220306 35.571 J0319+4130 20220316 32.214 J0319+4130 20220519 36.760 J0319+4130 20181214 27.076 J0319+4130 20181215 25.947 J0319+4130 20190115 26.354 J0319+4130 20190203 27.125 J0319+4130 20190227 28.041 J0319+4130 20190503 29.884 J0319+4130 20190809 27.529 J0319+4130 20190906 28.455 J0319+4130 20201110 27.454 J0319+4130 20201211 27.271 J0319+4130 20201218 27.917 J0319+4130 20201228 27.763 J0319+4130 20201229 26.997 J0319+4130 20201230 26.061 J0319+4130 20210114 28.430 J0319+4130 20210118 27.648 J0319+4130 20210209 27.351 J0319+4130 20210210 27.612 J0319+4130 20210211 27.169 J0319+4130 20210212 27.154 J0319+4130 20210213 27.819 J0319+4130 20210214 27.480 J0319+4130 20210215 29.556 J0319+4130 20210216 28.213 J0319+4130 20210328 29.513 J0319+4130 20210420 29.755 J0319+4130 20210730 31.933 J0319+4130 20211030 31.509 J0319+4130 20220331 30.618 J0319+4130 20220402 29.843 J0319+4130 20220417 30.427 J0319+4130 20230314 34.548 J0319+4130 20230402 35.222 J0319+4130 20230417 33.842 J0319+4130 20171115 26.640 J0319+4130 20171121 22.602 J0319+4130 20171126 29.667 3C 20180405 21.147 J0319+4130 20180908 22.277 J0319+4130 20180910 21.377 J0319+4130 20180913 21.296 J0319+4130 20180914 21.306 J0319+4130 20180915 18.784 J0319+4130 20180915 21.591 J0319+4130 20180916 21.691 J0319+4130 20180917 21.610 J0319+4130 20180918 21.538 J0319+4130 20180921 21.208 J0319+4130 20180922 21.519 J0319+4130 20180923 20.761 J0319+4130 20180924 21.005 J0319+4130 20180924 22.393 J0319+4130 20180925 22.598 J0319+4130 20180927 21.240 J0319+4130 20180929 22.178 J0319+4130 20180930 21.635 J0319+4130 20181002 21.062 J0319+4130 20181002 23.559 J0319+4130 20181004 20.194 J0319+4130 20181004 20.976 J0319+4130 20181004 21.982 J0319+4130 20181005 21.343 J0319+4130 20181005 21.293 J0319+4130 20181006 20.942 J0319+4130 20181008 20.379 J0319+4130 20181008 21.509 J0319+4130 20181009 21.931 J0319+4130 20181009 21.948 J0319+4130 20181010 21.721 J0319+4130 20181011 21.774 J0319+4130 20181019 21.414 J0319+4130 20181019 21.500 J0319+4130 20181022 22.296 J0319+4130 20181022 22.533 J0319+4130 20181024 22.976 J0319+4130 20181024 24.174 J0319+4130 20181025 21.057 J0319+4130 20181025 21.220 J0319+4130 20181025 21.378 J0319+4130 20181025 21.737 J0319+4130 20181025 21.067 J0319+4130 20181108 21.460 J0319+4130 20181108 21.817 J0319+4130 20181109 21.421 J0319+4130 20181109 21.669 J0319+4130 20181110 21.341 J0319+4130 20181110 21.436 J0319+4130 20181110 21.571 J0319+4130 20181111 21.300 J0319+4130 20181111 21.527 J0319+4130 20181115 21.679 J0319+4130 20181115 21.900 J0319+4130 20181116 21.648 J0319+4130 20181116 21.910 J0319+4130 20181124 21.311 J0319+4130 20181126 21.721 J0319+4130 20181210 24.648 J0319+4130 20181212 25.008 J0319+4130 20181214 22.712 J0319+4130 20181215 22.242 J0319+4130 20190115 22.693 J0319+4130 20190119 24.805 J0319+4130 20190120 22.688 J0319+4130 20190123 22.908 J0319+4130 20190127 22.472 J0319+4130 20190203 23.715 J0319+4130 20190227 24.981 J0319+4130 20190311 26.494 J0319+4130 20190316 26.298 J0319+4130 20190318 26.198 J0319+4130 20190323 27.490 J0319+4130 20190330 26.973 J0319+4130 20190401 25.347 J0319+4130 20190406 25.364 J0319+4130 20190420 25.284 J0319+4130 20190423 26.314 J0319+4130 20190504 25.649 J0319+4130 20190609 24.646 J0319+4130 20190611 24.472 J0319+4130 20190614 26.472 J0319+4130 20190615 27.563 J0319+4130 20190615 26.710 J0319+4130 20190616 25.063 J0319+4130 20190623 27.960 J0319+4130 20190625 26.401 J0319+4130 20190625 26.995 J0319+4130 20190702 26.735 J0319+4130 20190713 27.206 J0319+4130 20190715 27.778 J0319+4130 20190720 24.178 J0319+4130 20190723 27.032 J0319+4130 20190727 26.929 J0319+4130 20190728 26.209 J0319+4130 20190906 26.693 J0319+4130 20190910 29.693 J0319+4130 20190911 32.618 J0319+4130 20190926 24.704 J0319+4130 20190927 25.641 J0319+4130 20190930 25.367 J0319+4130 20191003 25.740 J0319+4130 20191003 27.248 J0319+4130 20191012 26.199 J0319+4130 20191012 26.842 J0319+4130 20191013 25.211 J0319+4130 20191015 26.483 J0319+4130 20201210 25.885 3C84 20201212 26.234 3C84 20201227 25.112 J0319+4130 20201229 25.867 3C84 20201230 26.267 J0319+4130 20210102 25.704 J0319+4130 20210112 25.797 J0319+4130 20210113 25.987 J0319+4130 20210117 25.420 J0319+4130 20210510 28.278 J0319+4130 20210615 29.647 J0319+4130 20210717 26.857 J0319+4130 20210809 27.153 J0319+4130 20211002 27.334 J0319+4130 20211002 27.831 J0319+4130 20211011 26.936 J0319+4130 20211221 27.436 3C84 20211230 26.823 3C84 20211231 26.404 3C84 20220104 28.315 3C84 20220104 26.500 3C84 20220315 29.644 J0319+4130 20230520 34.223 J0319+4130 20170616 28.854 J0319+4130 20170906 27.967 J0319+4130=3C84 20181110 25.205 3C84 20181114 25.136 3C84 20181117 19.091 J0319+4130 20181119 20.005 J0319+4130 20181119 19.388 J0319+4130 20181122 18.433 J0319+4130 20181214 18.574 J0319+4130 20190115 19.540 J0319+4130 20190127 18.856 J0319+4130 20190203 20.428 J0319+4130 20190228 23.096 J0319+4130 20190302 22.317 J0319+4130 20190530 26.985 J0319+4130 20190603 26.289 J0319+4130 20190616 24.278 J0319+4130 20190617 24.043 J0319+4130 20190618 24.908 J0319+4130 20190618 22.481 J0319+4130 20190619 24.404 J0319+4130 20190622 24.563 J0319+4130 20190626 23.586 J0319+4130 20190628 24.866 J0319+4130 20190704 23.301 J0319+4130 20190801 23.006 J0319+4130 20190906 22.561 J0319+4130 20200605 25.391 J0319+4130 20200819 22.730 J0319+4130 20200820 22.637 J0319+4130 20201217 21.571 J0319+4130 20201227 24.555 J0319+4130 20201231 21.260 J0319+4130 20210103 24.996 J0319+4130 20210105 25.569 J0319+4130 20210111 20.719 J0319+4130 20210112 25.607 J0319+4130 20210113 20.247 J0319+4130 20210120 25.091 3C84 20210128 23.178 J0319+4130 20210205 24.000 J0319+4130 20210212 23.995 J0319+4130 20210407 24.537 J0319+4130 20210916 25.198 J0319+4130 20211001 25.782 J0319+4130 20211002 25.495 J0319+4130 20211004 27.740 J0319+4130 20211009 26.217 J0319+4130 20211011 25.648 J0319+4130 20211016 26.135 J0319+4130 20211017 26.263 J0319+4130 20211020 27.375 J0319+4130 20211020 26.140 J0319+4130 20211021 26.494 J0319+4130 20211023 26.454 J0319+4130 20211110 25.718 3C84 20211211 24.881 3C84 20211212 25.908 3C84 20211218 26.027 3C84 20211219 25.453 3C84 20220318 27.131 J0319+4130 20220318 27.141 J0319+4130 20220325 24.989 J0319+4130 20220327 24.907 J0319+4130 20220409 25.054 J0319+4130 20220516 30.352 J0319+4130 20170906 27.546 J0319+4130=3C84 20190512 19.426 3C84 20190609 21.691 3C84 20190622 22.816 J0319+4130 20191006 20.064 J0319+4130 20191014 20.299 J0319+4130 20200809 22.216 3C84 20200918 21.648 3C84 20200922 25.359 J0319+4130 20200926 21.974 J0319+4130 20200929 21.404 J0319+4130 20200929 22.577 J0319+4130 20200929 22.468 J0319+4130 20201005 26.408 J0319+4130 20201006 28.001 J0319+4130 20201016 22.920 3C84 20201221 22.511 J0319+4130 20210113 22.738 J0319+4130 20210116 22.343 3C84 20210129 22.501 3C84 20210201 23.035 J0319+4130 20210202 22.232 3C84 20210203 22.337 3C84 20210207 23.496 J0319+4130 20210223 23.319 J0319+4130 20210224 22.691 J0319+4130 20210828 25.094 J0319+4130 20210906 23.523 J0319+4130 20211004 22.904 J0319+4130 20211011 21.890 J0319+4130 20211013 23.386 3C84 20211021 23.590 J0319+4130 20211029 23.810 3C84 20211031 22.952 3C84 20211031 22.539 J0319+4130 20211101 22.862 3C84 20211101 23.235 J0319+4130 20211103 23.495 J0319+4130 20211106 23.682 3C84 20211107 22.529 J0319+4130 20211212 23.951 3C84 20211216 23.103 J0319+4130 20211218 23.717 3C84 20220103 24.102 3C84 20220103 23.196 3C84 20220103 21.638 J0319+4130 20220312 23.291 3C84 20220316 22.691 3C84 20220328 21.790 3C84 20220424 24.104 3C84 20220814 28.112 J0319+4130 20171104 31.149 3C84 20171126 31.355 3C84
